1job_name: 'kubernetes-pods-user-test'
2scrape_interval: 30s # 可选，该 Job 的采集时间间隔，优先级高于全局配置
3scrape_timeout: 30s # 可选，该 Job 的采集超时时间，优先级高于全局配置
4metrics_path: /metrics # 必选，采集指标的 URI 路径，默认为 /metrics
5honor_labels: true # 可选，标签冲突处理策略，配置为 true 表示保留标签；配置为 false 表示重命名标签
6honor_timestamps: true # 可选，是否使用指标中的时间戳
7scheme: https # 必选，采集协议，支持 http 和 https ，默认为 http
8params: # 可选，http 协议参数，仅 scheme 为 http 时有效
9  p1: ["v1", "v2"]
10tls_config: # 可选，https 协议时的 TLS 配置，仅 scheme 为 https 时有效
11  ca_file: /etc/ca_file # 配置 CA 证书
12  cert_file: /etc/cert_file # 配置 TLS 证书
13  key_file: /etc/key_file # 配置 TLS 密钥
14  server_name: tls-server-demo # 配置 TLS 服务器名称
15  insecure_skip_verify: true # 是否禁用 https 服务器证书验证
16kubernetes_sd_configs:
17  - role: pod
18relabel_configs:
19- source_labels: [__meta_kubernetes_service_annotation_prometheus_io_scheme]
20  action: replace
21  target_label: __scheme__
22  regex: (https?)
23- source_labels: [__meta_kubernetes_pod_annotation_prometheus_io_scrape]
24  action: keep
25  regex: true
26- source_labels: [__meta_kubernetes_pod_annotation_prometheus_io_path]
27  action: replace
28  target_label: __metrics_path__
29  regex: (.+)
30- source_labels: [__meta_kubernetes_pod_label_app]
31  action: drop
32  regex: kube-state-metrics|node-exporter|dcgm-exporter|training-operator
33- source_labels: [__address__, __meta_kubernetes_pod_annotation_prometheus_io_port]
34  action: replace
35  regex: ([^:]+)(?::\d+)?;(\d+)
36  replacement: $1:$2
37  target_label: __address__
38- action: labelmap
39  regex: __meta_kubernetes_pod_label_(.+)
40- action: labeldrop
41  regex: (.+)_revision_hash|(.+)_template_generation
42
43

1job_name: 'test-pods'
2kubernetes_sd_configs:
3  - role: pod
4scrape_interval: 30s
5scrape_timeout: 30s
6metrics_path: /metrics # 必选，采集指标的 URI 路径，默认为 /metrics
7relabel_configs:
8- source_labels: [__meta_kubernetes_service_annotation_prometheus_io_scheme]
9  action: replace
10  target_label: __scheme__
11  regex: (https?)
12- source_labels: [__meta_kubernetes_pod_annotation_prometheus_io_scrape]
13  action: keep
14  regex: true
15- source_labels: [__meta_kubernetes_pod_annotation_prometheus_io_path]
16  action: replace
17  target_label: __metrics_path__
18  regex: (.+)
19- source_labels: [__meta_kubernetes_pod_label_app]
20  action: drop
21  regex: kube-state-metrics|node-exporter|dcgm-exporter|training-operator
22- source_labels: [__address__, __meta_kubernetes_pod_annotation_prometheus_io_port]
23  action: replace
24  regex: ([^:]+)(?::\d+)?;(\d+)
25  replacement: $1:$2
26  target_label: __address__
27- action: labelmap
28  regex: __meta_kubernetes_pod_label_(.+)
29- action: labeldrop
30  regex: (.+)_revision_hash|(.+)_template_generation
