1job_name: '<任务名称>'
2scrape_interval: 30s # 可选，该 Job 的采集时间间隔，优先级高于全局配置
3scrape_timeout: 30s # 可选，该 Job 的采集超时时间，优先级高于全局配置
4metrics_path: /metrics # 必选，采集指标的 URI 路径，默认为 /metrics
5honor_labels: true # 可选，标签冲突处理策略，true 表示保留标签，false 表示重命名冲突标签
6honor_timestamps: true # 可选，是否使用指标中的时间戳
7scheme: https # 必选，采集协议，支持 http 和 https，默认为 http
8params: # 可选，HTTP 协议参数，仅在 scheme 为 http 时有效
9  p1: ['<参数值>']
10tls_config: # 可选，HTTPS 协议下的 TLS 配置，仅在 scheme 为 https 时有效
11  ca_file: '<CA 证书路径>'
12  cert_file: '<TLS 证书路径>'
13  key_file: '<TLS 密钥路径>'
14  server_name: '<TLS 服务器名称>'
15  insecure_skip_verify: true # 是否禁用 HTTPS 服务器证书验证
16kubernetes_sd_configs:
17  - role: pod
18relabel_configs:
19  - source_labels: [__meta_kubernetes_service_annotation_prometheus_io_scheme]
20    action: replace
21    target_label: __scheme__
22    regex: (https?)
23  - source_labels: [__meta_kubernetes_pod_annotation_prometheus_io_scrape]
24    action: keep
25    regex: true
26  - source_labels: [__meta_kubernetes_pod_annotation_prometheus_io_path]
27    action: replace
28    target_label: __metrics_path__
29    regex: (.+)
30  - source_labels: [__meta_kubernetes_pod_label_app]
31    action: drop
32    regex: kube-state-metrics|node-exporter|dcgm-exporter|training-operator
33  - source_labels: [__address__, __meta_kubernetes_pod_annotation_prometheus_io_port]
34    action: replace
35    regex: ([^:]+)(?::\\d+)?;(\\d+)
36    replacement: $1:$2
37    target_label: __address__
38  - action: labelmap
39    regex: __meta_kubernetes_pod_label_(.+)
40  - action: labeldrop
41    regex: (.+)_revision_hash|(.+)_template_generation

1job_name: 'kubernetes-pods-user-test'
2kubernetes_sd_configs:
3  - role: pod
4scrape_interval: 30s
5scrape_timeout: 30s
6metrics_path: /metrics
7relabel_configs:
8  - source_labels: [__meta_kubernetes_service_annotation_prometheus_io_scheme]
9    action: replace
10    target_label: __scheme__
11    regex: (https?)
12  - source_labels: [__meta_kubernetes_pod_annotation_prometheus_io_scrape]
13    action: keep
14    regex: true
15  - source_labels: [__meta_kubernetes_pod_annotation_prometheus_io_path]
16    action: replace
17    target_label: __metrics_path__
18    regex: (.+)
19  - source_labels: [__meta_kubernetes_pod_label_app]
20    action: drop
21    regex: kube-state-metrics|node-exporter|dcgm-exporter|training-operator
22  - source_labels: [__address__, __meta_kubernetes_pod_annotation_prometheus_io_port]
23    action: replace
24    regex: ([^:]+)(?::\\d+)?;(\\d+)
25    replacement: $1:$2
26    target_label: __address__
27  - action: labelmap
28    regex: __meta_kubernetes_pod_label_(.+)
29  - action: labeldrop
30    regex: (.+)_revision_hash|(.+)_template_generation
